25 mm C-Mount Lens Fujinon CF25ZA-1S - 1.8/ 25mm

The Fujinon CF25ZA-1S Machine Vision C-mount lens supports a large 1.1-inch high-resolution sensor with a pixel pitch of 2.5 μm (equivalent to 23 megapixels). The relative illumination reaches up to more than 90% * and allows a clear picture from the center of the image to the edge area. The compact design and the new shock-resistant design make the Obejtkiv resistant to shock and vibration, making it suitable for a wide variety of manufacturing environments.

• Fujinon
• 23MPixel Anti Shock & Vibration
• for 1.1" camera
• for pixel size 2.5μm
• Focal length 25mm
• Aperture 1.8-16
• manually controlled, small construction lens
• for C-mount
• Secure fixing screws for aperture and focus

For an overview of the entire series, see the following link:  Fujinon CF-ZA-1S series for Machine Vision Applications

► Ultrahigh-resolution models compatible with large sensors with high pixel count of 1.1-inch・2.5µm pixel pitch (equivalent to 23 megapixels)

These lenses are for use with ultrahigh resolution machine vision cameras and are compatible with large sensors with high pixel count of 1.1-inch・2.5µm pixel pitch (equivalent to 23 megapixels). Fujifilm's unique 4D High Resolution technology mitigates resolution degradation that results from changes in shooting distance and aperture setting.

► Efficient high-precision inspection capability at relative illumination ratio of 90% and higher

At the F4 aperture setting, which is frequently selected by users, the lenses achieve bright imagery from the center of the image to the periphery. This eliminates the need for light intensity compensation, which may cause noise into the image, facilitating efficient high-precision product inspections.

► Compact, anti-shock and vibration design makes the lenses suitable for a diverse range of manufacturing environments

The lenses have the world's smallest external diameter of just 39mm. This contributes to the overall compactness of the machine vision system.

► Excellent convenience and reliability

The lens uses a unique mechanism that does not change the overall length of the lens even during focusing. Lenses can be accessed easily to achieve the desired shooting distance.
